GD80 80KGS SUS304 internal fire door hinges 3D hidden hinges
· The product is SUS304 material
· Carry the door weighs 80 kg maximum
· The maximum opening angle is 180 °
· Minimum of 40 mm door leaf Thickness
· Can be realized up and down adjustment ± 1.5 mm
left and right the adjustment ± 1.5 mm,before
and after the adjustment ± 1.0 mm,easy to install and use
- Overview
- Parameter
- Inquiry
- Related Products
- 100% 10 years life, Heavy duty 80kgs for 2hinges, 3hinges for 100kgs
- 200000circle life ,it at least working for 12 years
- Hinges open a full 180 degrees and have a laminated link which ensures smooth hinge movement.
- Easy to open and close, less noise.
- Convenient to fix with hole, cross hinge fit for door round corner fitting, perfect for cabinet door, sliding door etc
- 3D adjusted up and down, left,right, front/back etc
- Suitable for fire rated door
GD80 80KGS SUS304 internal fire door hinges 3D hidden hinges
|
Length(door/frame) |
112 / 112 mm |
|
Width(door/frame) |
29 / 29mm |
|
Material |
Stainlesssteel 3D conceal hinges |
|
Loading for 2hinge |
80kgs |
|
EN1634 Fire rated |
yes |
|
Opening angel |
≤ 180° |
